Adjustable 90° Lens Linear High Bay for Aisles Applications, 15 to 25 ft Ceilings
Lumens:
Watts:
Color Temp:
3 Year Warranty
Affordable LED Linear High Bay for Large, Open Spaces
- Cuts Energy Costs: Delivers 135 lm/W for bright lighting that's easy on your utility bills.
- Easy Installation: Suspend from chains or pendant-mount on a conduit.
- Smooth Dimming: 0-10V dimming capability with a high-quality, flicker-free driver.
- Built to Last: Excellent heat distribution & rated for use in both dry and damp locations.
An excellent choice for exhibition halls, warehouses, work areas, retail stores, gymnasiums, and industrial spaces that require bright, dependable lighting.
Saves $/year in energy costs*
Buying 6 or more boxes?
Get a better price & free shipping:
Affordable LED Linear High Bay for Large, Open Spaces
- Cuts Energy Costs: Delivers 135 lm/W for bright lighting that's easy on your utility bills.
- Easy Installation: Suspend from chains or pendant-mount on a conduit.
- Smooth Dimming: 0-10V dimming capability with a high-quality, flicker-free driver.
- Built to Last: Excellent heat distribution & rated for use in both dry and damp locations.
An excellent choice for exhibition halls, warehouses, work areas, retail stores, gymnasiums, and industrial spaces that require bright, dependable lighting.
Saves $/year in energy costs*
See how much you would save in energy
costs by allowing access to your location.
Choose options
Lumens:
Watts:
Color Temp:
3 Year Warranty
Buying 6 or more boxes?
Get a better price & free shipping:
Lumens:
Watts:
Color Temp:
3 Year Warranty
Buying 6 or more boxes?
Get a better price & free shipping:
SPECIFICATIONS
| Wattage(s) | 120W/165W/220W |
| Replaces Wattage(s) | Up to 750W |
| Light Output | 29,700/21,450/16,200 lumens |
| Luminous Efficacy (lm/W) | 135 lm/W |
| Average Lamp Life | 50,000 hours |
| Color Temperature(s) | 4000K/5000K |
| CRI (Color Accuracy) | >80 |
| Dimming | 0-10V |
| Beam Angle | 90° |
| Recommended Installation Height | 15 to 25 ft |
| Working Environment | Indoors |
| Input Voltage | 120-277VAC |
| Dimensions | 24.65" x 12.8" x 2" |
| Certification | ETL |
| Warranty | 1 Year |
COMPARE KEY FEATURES
Linear LED High Bay – 2 CCT – 220/165/120W
|
Linear LED High Bay – 2 CCT – Swappable Optics – 270/230/200W
|
LED Linear High Bay - 4000K/5000K CCT - 60/105/140/210W Selectable
|
|
|---|---|---|---|
| Wattage | 120W/165W/220W | 200/230/270W Selectable | 60/105/140/210W Selectable |
| Efficacy | 135 lm/W | 150 lm/W | Standard Efficiency Model: @4000K: 162 lm/W @5000K: 160 lm/W High Efficiency Model: @4000K: 172 lm/W @5000K: 170 lm/W |
| Color Temperature (CCT) | 4000K/5000K | 4000K/5000K Selectable | 4000/5000K Selectable (Call for 4000K or 5000K fixed) |
| Color Accuracy (CRI) | >80 | 80 | 80 |
| Temperature Rating | -40°F to +122°F | -25°C to +50°C (-13°F to +122°F) | |
| Warranty | 1 Year | 5 Years | 5 Years |
|
$67.99
|
$73.00
View Details
|
$98.95
View Details
|
Key Features
Budget Friendly
Customizable Lighting
Quick & Easy Install
Powerful LED Linear High Bay for Large Spaces
High Luminous Output: Delivers 135 lm/W for bright, energy-efficient lighting.
Easy Installation: Suitable for dry and damp locations.
Durable, Flicker-Free Performance
Smooth Dimming: 0-10V dimming capability with a high-quality, flicker-free driver.
Built to Last: ETL & FCC listed, with LM79 & LM80 testing for proven reliability.
An excellent choice for warehouses, gymnasiums, and industrial spaces requiring bright, dependable lighting.
Light Output
This light is wattage-selectable. Click a wattage to see the light output for that setting.
