240W Selectable UFO LED High Bay, Ceilings Up to 35 ft
240W Selectable UFO LED High Bay, Ceilings Up to 35 ft
240W Selectable UFO LED High Bay, Ceilings Up to 35 ft
ELEDLights
0 Reviews
240W Selectable UFO LED High Bay, Ceilings Up to 35 ft
Regular price$124.99
High-output, field-customizable UFO high bay — adjust beam, wattage, and CCT on-site.
- Rotatable lens: 60°, 85°, 105°; dip switches select 4000K/5000K and 144W/192W/240W.
- 0-10V dimming and sensor-port ready for plug-in motion control — up to 38,400 lumens.
- One model number covers mixed-use facilities — configure each fixture during install.
Need More? Let's Talk Text (858) 650-9400 or Request Quote
High-output, field-customizable UFO high bay — adjust beam, wattage, and CCT on-site.
- Rotatable lens: 60°, 85°, 105°; dip switches select 4000K/5000K and 144W/192W/240W.
- 0-10V dimming and sensor-port ready for plug-in motion control — up to 38,400 lumens.
- One model number covers mixed-use facilities — configure each fixture during install.
Choose options
Details
The Most Versatile UFO-Style High Bay on the Market
All Customizable During Install - Beam Angle, Wattage, CCT
Outfit Your Entire Property, even multiple properties, with just one model number.
Dial-in the Exact Lighting Performance Needed:
- Rotatable Lens adjusts the beam to best suit open areas, aisles, and work areas.
- Dip-Switches adjust the color temperature between neutral and cool as well as adjusting the power use to 100%, 80%, or 60% to best accommodate each ceiling height and application.
- 0-10V Dimming capable when connected to a dimming controller.
- Add a plug-in motion sensor for additional energy savings.
Ideal for a wide range of applications, from warehouses to shopping malls, gymnasiums to airports, exhibition halls to industrial facilities.
Specs
| Wattage(s) | 144W/192W/240W |
| Replaces Wattage(s) | Up to 750W |
| Light Output |
At 4000K: 38,400/30,720/23,040 lumens At 5000K: 36,000/28,800/21,600 lumens |
| Luminous Efficacy (lm/W) |
4000K: 160 lm/W 5000K: 150 lm/W |
| Average Lamp Life | 50,000 hours |
| Color Temperature(s) | 4000K/5000K |
| CRI (Color Accuracy) | 80 |
| Dimming | 0-10V |
| Occupancy Sensor | Plug-in sensor available as accessory |
| Beam Angle | 60°/85°/105° selectable at install |
| Installation | Stainless steel loop included for hanging; adjustable bracket available for ceiling mounting |
| Working Environment | Indoor |
| Enclosure Rating | IP65, IK08 |
| Input Voltage | 120-277 VAC, 50/60 Hz |
| Temperature Rating | -30°C to +50°C (-22°F to +122°F) |
| Housing Material | Aluminum Alloy with Polycarbonate Optical Lens |
| Housing Color | Black |
| Dimensions | φ11.61”x7.36” |
| Weight | 5.73 lbs |
| Certification | DLC 5.1, ETL |
| Warranty | 5 Years |
Data SheetCompare Key Features
Compare
240W Selectable UFO LED High Bay, Ceilings Up to 35 ft
|
310W Selectable UFO LED High Bay, Ceilings 30 to 40 ft
|
350W Selectable UFO LED High Bay, Ceilings Up to 50 ft
|
|
|---|---|---|---|
| Wattage | 144W/192W/240W | 240W/270W/320W | 140W/210W/280W/350W |
| Efficacy | 4000K: 160 lm/W 5000K: 150 lm/W |
150 lm/W | Up to 190 lm/W |
| Color Temperature (CCT) | 4000K/5000K | 4000K/5000K | 5000K |
| Color Accuracy (CRI) | 80 | 80 | 70 |
| Temperature Rating | -30°C to +50°C (-22°F to +122°F) | -40˚F to 122˚F | -40°F to 131°F (at 350W setting) -40°F to 149°F (all other wattage settings) |
| Warranty | 5 Years | 5 Years | 5 Years |
|
$117.49
|
$131.49
View Details
|
$254.99
View Details
|
×
×
Instant Rebates
Check if your utility offers rebates for new LED lights installed in commercial & industrial buildings:
×
