Mann Manufacturing

350W Selectable UFO LED High Bay, Ceilings Up to 50 ft

Mann Manufacturing

0 Reviews

SKU: HBM5D350WS50V120

$254.99

Ultra-high-output UFO high bay for 30ft+ ceilings running around the clock — built to last.

Up to 190 lm/W with 4 selectable wattages (140W/210W/280W/350W) — up to 66,500 lumens.
Hook and 3/4" conduit pendant mounting included — 0-10V dimming from 100% to 10%.
5-year warranty for distribution centers, aircraft hangars, and cold-storage industrial plants.

Voltage

Variant

Need More? Let's Talk Text (858) 650-9400 or Request Quote

Ultra-high-output UFO high bay for 30ft+ ceilings running around the clock — built to last.

Up to 190 lm/W with 4 selectable wattages (140W/210W/280W/350W) — up to 66,500 lumens.
Hook and 3/4" conduit pendant mounting included — 0-10V dimming from 100% to 10%.
5-year warranty for distribution centers, aircraft hangars, and cold-storage industrial plants.

Details

Lots of Light without Lots of Overhead: Exceptional luminous efficacy (up to 190 lm/W).
Reduce Electric Costs by 60% when replacing 100W metal halide lamps.

Simple installation with both hook and pendant (3/4" conduit) mounting included.
Reliable performance even in wet, sub-freezing, and hot environments.
Fine-tunable lighting levels with 100% to 10% dimming capability.

This light is ideal for properties with ceilings over 30 feet, especially properties with a mix of high and very high ceilings.

Wattage(s)	140W/210W/280W/350W
Replaces Wattage(s)	Up to 1000W
Light Output	26,600 to 62,000 lumens
Luminous Efficacy (lm/W)	Up to 190 lm/W
Average Lamp Life	50,00-hour LED lifespan
Color Temperature(s)	5000K
CRI (Color Accuracy)	70
Dimming	0-10V
Dimming Range	100% to 10%
Occupancy Sensor	Plug-in sensor available as accessory
Beam Angle	120°
Installation	Hook mount with included hook or pendant mount on 3/4" conduit
Working Environment	Indoor
Enclosure Rating	UL cUL Wet Location
Input Voltage	120-277 VAC or 347-480 VAC
Temperature Rating	-40°F to 131°F (at 350W setting) -40°F to 149°F (all other wattage settings)
Housing Material	Die-cast aluminum alloy
Housing Color	Bronze
Dimensions	φ24.25" x 7.47” high
Weight	17.32 lbs
Certification	DLC 5.1, UL cUL Wet Location
Warranty	5 Years

Data Sheet

Install Guide

	350W Selectable UFO LED High Bay, Ceilings Up to 50 ft	410W Selectable UFO LED High Bay
Wattage	140W/210W/280W/350W	164W/246W/328W/410W
Efficacy	Up to 190 lm/W	Up to 190 lm/W
Color Temperature (CCT)	5000K	5000K
Color Accuracy (CRI)	70	70
Temperature Rating	-40°F to 131°F (at 350W setting) -40°F to 149°F (all other wattage settings)	-40°F to 131°F (at 328W and 410W setting) -40°F to 149°F (all other wattage settings)
Warranty	5 Years	5 Years
	$254.99	$369.99 View Details
