Ideal for residential streets, rural pathways, small parking lots, and storage yards, this 20W off-grid solar LED area light delivers up to 4,000 lumens with adaptive output and a field-replaceable battery.
- 4000K and 5000K options
- Timed dimming, motion-sensing, & constant output modes
- LiFePO4 battery for 2000+ charging cycles
Bulk Pricing: Text (858) 650-9400 or Request Quote
Ideal for residential streets, rural pathways, small parking lots, and storage yards, this 20W off-grid solar LED area light delivers up to 4,000 lumens with adaptive output and a field-replaceable battery.
- 4000K and 5000K options
- Timed dimming, motion-sensing, & constant output modes
- LiFePO4 battery for 2000+ charging cycles
Choose options
Bulk Pricing: Text (858) 650-9400 or Request Quote
Bulk Pricing: Text (858) 650-9400 or Request Quote
Details
Set It and Forget It—4,000 Lumens Solar Area Light
- Install Anywhere – No electrical connection required
- 200 lm/W Efficiency – More light per watt for brighter, longer operation
- 49' Motion Sensor – Wakes at 100% when needed
- Auto-Dimming – For smart power use
- Field-Replaceable Battery – Ensures years of reliable operation
- Tilt-Adjustable Head – Maximizes solar collection
Great for residential street lighting, small parking lots, rural pathways and access roads, and storage yards.
If you need other mounts, color temperatures, light distribution patterns, or housing colors, you can special order through ELEDLights—get in touch!
Specs
| Wattage(s) | 20W |
| Light Output | 4,000 lumens |
| Luminous Efficacy (lm/W) | 200 lm/W |
| Battery | Grade A LiFePO4, 256Wh (12.8V/20Ah) |
| Solar Panel Wattage | 18V/36W |
| Solar Charge Controller | MPPT |
| Run Time |
Full power: 11 hours Motion sensor mode: Up to 55 hours Time control mode: Up to 28 hours |
| Operation Method |
Three Operating Mode Types:** Motion Sensor Modes: 40%-100% Motion Sensor Mode 20%-80% Motion Sensor Mode (default) Time Control Modes: Night Owl Mode Early Bird Mode Timer Mode - 8 Hours Timer Mode - 4 Hours Constant Working Modes: 100% Constant Mode 70% Constant Mode 40% Constant Mode **Selectable by remote control. See Data Sheet for mode parameters. |
| Color Temperature(s) | 4000K or 5000K |
| CRI (Color Accuracy) | >70 |
| Occupancy Sensor | Microwave Motion Sensor |
| Motion Sensor Coverage | Up to 49' (15m) |
| Charge Time | 7 hours |
| Light Distribution Pattern |
Type III (T3)
Learn More
×
Light Distribution OptionsType III Beam  Throws light forward and sideways. Suitable for either perimeter lighting, or, when fixtures are installed back-to-back, for interior poles. Type IV Beam  Provides forward directed light with minimal backlighting - great for perimeter installations. Type V Beam  Creates a square umbrella pattern of light ideal for interior (rather than perimeter) pole locations. |
| Light Type | Solar |
| Temperature Rating |
Operating: -4°F to 140°F Charging: 32°F to 140°F |
| Dimensions | 26" x 17" x 4" |
| Weight | 21.4 |
| Certification | UL Listed |
| Warranty | 5 Years |
| Additional Specifications |
*The temperature can impact the battery’s charging and normal operation. If your site’s temperature is under 32°F, we advise you to use the SUNLIKE PRO model to achieve better lighting results.
|
Data SheetCompare Key Features
Compare
20W Solar LED Area Light
|
30W Solar LED Street & Area Light
|
25W Decorative Solar Pathway & Area Light
|
|
|---|---|---|---|
| Light Output | 4,000 lumens | 6,000 lumens | 4,500 lumens |
| Color Temperature (CCT) | 4000K or 5000K | 3000K, 4000K, or 5000K | 4000K |
| Charging Time | 7 hours | 7 hours | 11 hours* |
| Run Time | Full power: 11 hours Motion sensor mode: Up to 55 hours Time control mode: Up to 28 hours |
Full power: 11 hours Motion sensor mode: Up to 55 hours Time control mode: Up to 28 hours |
Full power: 26 hours Motion sensor mode: Up to 110 hours Time control mode: Up to 56 hours |
| Temperature Rating | Operating: -4°F to 140°F Charging: 32°F to 140°F |
Standard: Operating: -4°F to 122°F Charging: 0°C/32°F to 149°F PRO: Operating: -22°F to 140°F Charging: -22°F to 140°F |
Operating: -4°F to 140°F Charging: 32°F to 140°F |
| Warranty | 5 Years | 5 Years | 5 Years |
|
