Engineered for critical applications and cold-weather regions, this 45W hybrid solar LED area light combines off-grid solar savings with automatic grid backup and cold-weather operation down to -22°F.
- Output up to 9,600 lumens
- Solar-first with automatic grid backup
- Charges to -22°F, full charge in as little as 5 hrs
Bulk Pricing: Text (858) 650-9400 or Request Quote
Engineered for critical applications and cold-weather regions, this 45W hybrid solar LED area light combines off-grid solar savings with automatic grid backup and cold-weather operation down to -22°F.
- Output up to 9,600 lumens
- Solar-first with automatic grid backup
- Charges to -22°F, full charge in as little as 5 hrs
Choose options
Details
Stable Performance Even in Cloudy, Rainy, or Cold Conditions
Reduce your energy footprint without being left in the dark. This solar area light combines the efficiency of solar energy with the reliability of the grid by automatically switching from solar battery power to grid when battery voltage is low.
- Works in Cold Weather – Innovative battery technology provides efficient performance in temps down to -22˚F.
- Over 190 lm/W Efficiency – More light per watt for brighter, longer operation.
- 49' Motion Sensor – Wakes at 100% when needed.
- Tilt-Adjustable Head – Maximizes solar collection.
Need More Options? – Contact ELEDLights about special order options for mounting brackets, color temperature, light distribution pattern, input voltage, housing color, or light output.
Specs
| Wattage(s) | 45W |
| Light Output | 8,600 lumens |
| Luminous Efficacy (lm/W) | 190 lm/W |
| Battery | Cold Weather Battery, 492Wh (12.8V) |
| Solar Panel Wattage | 94W |
| Solar Charge Controller | MPPT |
| Run Time |
Full power: 12 hours without grid power Motion sensor mode: Up to 50 hours without grid power Time control mode: Up to 18 hours without grid power |
| Operation Method |
Three Operating Mode Types:** Motion Sensor Modes: 40%-100% Motion Sensor Mode 20%-80% Motion Sensor Mode (default) Time Control Modes: Night Owl Mode Early Bird Mode Timer Mode - 8 Hours Timer Mode - 4 Hours Constant Working Modes: 100% Constant Mode 70% Constant Mode 40% Constant Mode **Selectable by remote control. See Data Sheet for mode parameters. |
| Color Temperature(s) | 5000K |
| Occupancy Sensor | Microwave Motion Sensor |
| Motion Sensor Coverage | Up to 49' (15m) |
| Charge Time | 5-6 hours* |
| Light Distribution Pattern |
Type III (T3)
Learn More
×
Light Distribution OptionsType III Beam  Throws light forward and sideways. Suitable for either perimeter lighting, or, when fixtures are installed back-to-back, for interior poles. Type IV Beam  Provides forward directed light with minimal backlighting - great for perimeter installations. Type V Beam  Creates a square umbrella pattern of light ideal for interior (rather than perimeter) pole locations. |
| Enclosure Rating | IP65 |
| Light Type | Solar |
| Input Voltage | 100-277V, 50/60 Hz |
| Temperature Rating |
Operating: -22°F to 140°F Charging: -22°F to 140°F |
| Housing Material | Die cast aluminum |
| Dimensions | 43.5" x 19.5" x 4.4" |
| Weight | 63 lbs |
| Certification | UL Listed |
| Warranty | 5 Years |
| Additional Specifications | * The solar charge time data is based on 77° F ambient temperature with the panel pointed directly at the solar radiation. The standard radiation value is 1000W/m2. |
