Economy, Quick Installation Linear Low Bay for Ceilings 10 to 18 ft
Lumens:
Watts:
Color Temp:
1 Year Warranty
92 in stockThe Contractor's Choice
- Designed specifically for fast installation
- Small package allows you to fit up to 3x more on a lift
- Quality construction & a glare-reducing lens
- Smooth 0-10V dimming
- Starts in temps down to -40°F, operates in temps up to 131°F
Perfect for bulk installs in warehouses, retail stores, manufacturing facilities, and other locations with ceilings up to 15 feet.
Saves $/year in energy costs*
Buying 12 or more?
Get a better price:
The Contractor's Choice
- Designed specifically for fast installation
- Small package allows you to fit up to 3x more on a lift
- Quality construction & a glare-reducing lens
- Smooth 0-10V dimming
- Starts in temps down to -40°F, operates in temps up to 131°F
Perfect for bulk installs in warehouses, retail stores, manufacturing facilities, and other locations with ceilings up to 15 feet.
Saves $/year in energy costs*
See how much you would save in energy
costs by allowing access to your location.
Choose options
Lumens:
Watts:
Color Temp:
1 Year Warranty
92 in stock
Buying 12 or more?
Get a better price:
Lumens:
Watts:
Color Temp:
1 Year Warranty
92 in stock
Buying 12 or more?
Get a better price:
SPECIFICATIONS
| Wattage(s) | 90W |
| Replaces Wattage(s) | 175W |
| Light Output | 12,200 lumens |
| Luminous Efficacy (lm/W) | 136 lm/W |
| Average Lamp Life | 50,000 hours |
| Color Temperature(s) | 4000K or 5000K |
| Dimming | 0-10V |
| Base Type | Fixture |
| Installation | Wire fixture into mains. Steel wires included for hanging. |
| Working Environment | Indoor |
| Light Type | Wired Fixture |
| Input Voltage | 120V-277V |
| Temperature Rating | -40°F to 131°F |
| Housing Material | Die-cast aluminum |
| Dimensions | 12.3" L x 12.6" W x 2" H |
| Weight | 5.84 lbs |
| Certification | UL |
| Warranty | 1 Year |
FIXTURE CALCULATOR
Our easy tool tells you how many lights you need & how far apart they should be installed.
Click the cube icon
& enter the room's dimensions. "Workplane Height" is where the light levels will be measured from. For example, 2.5 ft is about desk height. "Suspension Length" is how far your fixture will hang below the ceiling. If the fixture will be flush with the ceiling or recessed, enter 0.
As you make changes, the layout updates instantly to show recommended fixture (luminaire) quantities and spacing. Click the printer icon
in the top bar to get a report you can print or share.
Key Features
Compact Design for Easy Install
Glare-Control Optics
Smart Models Available
Compact, Low-Profile 1x1 Lighting Fixture
Light Output Comparable to 1x2 Lights: Same brightness in a smaller package.
Space-Saving: Easier to store by taking up half the space.
Contractor-Friendly: Installations go about 30% faster.
Design Highlights:
- Glare-Reducing Lenses
- Dimmable (0-100%)
- Weighs less than 6 lbs.
- Fit up to 3x more on a lift
- Fit up to 2x more on a pallet
Perfect for bulk installs in warehouses, retail stores, manufacturing facilities, and other high-ceiling applications.
Special Order Models Available (Contact us for pricing & lead time)
Motion-Detection Model: An added motion sensor is a great security & energy savings booster.
Emergency Lighting Model: A backup battery provides 90 minutes of light during power outages.
