Ultra-Bright High-Bay Light for Wide Ambient Temperature Ranges, Ceilings to 60ft
Lumens:
Watts:
Color Temp:
5 Year Warranty
Illuminate Very High Ceiling Locations at a Very Low Energy Cost
- Lots of Light without Lots of Overhead: Exceptional luminous efficacy (up to 190 lm/W).
- Reduce Electric Costs by 60% when replacing 100W metal halide lamps.
Easy-to-Install, Reliable, Dimmable High Bay Lighting
- Simple installation with both hook and pendant (3/4" conduit) mounting included.
- Reliable performance even in wet, sub-freezing, and hot environments.
- Fine-tunable lighting levels with 100% to 10% dimming capability.
This light is ideal for properties with ceilings over 30 feet, especially properties with a mix of high and very high ceilings.
Saves $/year in energy costs*
Buying 12 or more?
Get a better price & free shipping:
Illuminate Very High Ceiling Locations at a Very Low Energy Cost
- Lots of Light without Lots of Overhead: Exceptional luminous efficacy (up to 190 lm/W).
- Reduce Electric Costs by 60% when replacing 100W metal halide lamps.
Easy-to-Install, Reliable, Dimmable High Bay Lighting
- Simple installation with both hook and pendant (3/4" conduit) mounting included.
- Reliable performance even in wet, sub-freezing, and hot environments.
- Fine-tunable lighting levels with 100% to 10% dimming capability.
This light is ideal for properties with ceilings over 30 feet, especially properties with a mix of high and very high ceilings.
Saves $/year in energy costs*
See how much you would save in energy
costs by allowing access to your location.
Choose options
Lumens:
Watts:
Color Temp:
5 Year Warranty
Buying 12 or more?
Get a better price & free shipping:
Lumens:
Watts:
Color Temp:
5 Year Warranty
Buying 12 or more?
Get a better price & free shipping:
SPECIFICATIONS
| Wattage(s) | 164W/246W/328W/410W |
| Replaces Wattage(s) | Up to 1000W |
| Light Output | 31,000 to 72,000 lumens |
| Luminous Efficacy (lm/W) | Up to 190 lm/W |
| Average Lamp Life | 50,000 hours |
| Color Temperature(s) | 5000K |
| CRI (Color Accuracy) | 70 |
| Dimming | 0-10V |
| Dimming Range | 100% to 10% |
| Occupancy Sensor | Plug-in sensor available as accessory |
| Beam Angle | 120° |
| Installation | Hook mount with included hook or pendant mount on 3/4" conduit |
| Working Environment | Indoor |
| Enclosure Rating | UL cUL Wet Location |
| Input Voltage | 120-277 VAC or 347-480 VAC |
| Temperature Rating |
-40°F to 131°F (at 328W and 410W setting) -40°F to 149°F (all other wattage settings) |
| Housing Material | Die-cast aluminum alloy |
| Housing Color | Bronze |
| Dimensions | φ24.25" x 7.47” high |
| Weight | 19.47 lbs |
| Certification | DLC 5.1, UL cUL Wet Location |
| Warranty | 5 Years |
FIXTURE CALCULATOR
Our easy tool tells you how many lights you need & how far apart they should be installed.
Click the cube icon
& enter the room's dimensions. "Workplane Height" is where the light levels will be measured from. For example, 2.5 ft is about desk height. "Suspension Length" is how far your fixture will hang below the ceiling. If the fixture will be flush with the ceiling or recessed, enter 0.
As you make changes, the layout updates instantly to show recommended fixture (luminaire) quantities and spacing. Click the printer icon
in the top bar to get a report you can print or share.
Key Features
Great for Ceilings > 30ft
Smart Control Ready
Super Bright Capability
Illuminate Very High Ceiling Locations at a Very Low Energy Cost
- Lots of light without Lots of Overhead: Exceptional luminous efficacy (up to 190 lm/W).
- 100,000-hour Operating Life = 11+ years of illumination on average with 24/7 operation.
- Reduce Electric Costs by 60% when replacing 100W metal halide lamps.
Easy-to-Install, Reliable, Dimmable High Bay Lighting
- Simple installation with both hook and pendant (3/4" conduit) mounting included.
- Reliable performance even in wet, sub-freezing, and hot environments.
- Fine-tunable lighting levels with 100% to 10% dimming capability.
This light is ideal for properties with ceilings over 30 feet, especially properties with a mix of high and very high ceilings.
Light Output
This light is wattage-selectable. Click a wattage to see the light output for that setting.
