54W Selectable RAB LED Post Top Retrofit Lamp - EX39
54W Selectable RAB LED Post Top Retrofit Lamp - EX39
54W Selectable RAB LED Post Top Retrofit Lamp - EX39
54W Selectable RAB LED Post Top Retrofit Lamp - EX39
Replace traditional metal halide or high pressure sodium HID lamps with significantly less energy usage and significantly more lamp life.
- Adjustable wattage and CCT allows for in-field customization
- Rated for use in enclosed fixtures in dry or damp locations
- Universal 100-277V voltage for flexible installation
Replace traditional metal halide or high pressure sodium HID lamps with significantly less energy usage and significantly more lamp life.
- Adjustable wattage and CCT allows for in-field customization
- Rated for use in enclosed fixtures in dry or damp locations
- Universal 100-277V voltage for flexible installation
Choose options
Specs
| Wattage(s) | 36W/45W/54W |
| Replaces Wattage(s) | 150W/175W/200W Metal Halide or High Pressure Sodium |
| Light Output | 5,580/6,970/8,370 lumens |
| Luminous Efficacy (lm/W) | 155 lm/W |
| Average Lamp Life | 50,000 hours (L70) |
| Color Temperature(s) | 3000K/4000K/5000K (Field Adjustable via dip switch) |
| CRI (Color Accuracy) | 80 CRI |
| Dimming | Yes, by adjusting the wattage (light output) dipswitch located on the lamp. |
| Occupancy Sensor | Integrated AUX port for lamp-level sensor control |
| Bulb Shape | Post Top |
| Base Type | EX39 |
| Beam Angle | 360° |
| Ballast Compatibility | UL Type B, Ballast Bypass |
| Installation | Universal mounting, horizontal or vertical, in open or enclosed fixtures in damp or dry locations |
| Enclosure Rating | IP64 |
| Input Voltage | 100-277V |
| Power Factor | ≥0.9 |
| THD (Total Harmonic Distortion) | ≤20% |
| Surge Protection | 4 kV |
| Operating Temperature | -22°F to 140°F (-30°C to 60°C) |
| Housing Material | Polycarbonate |
| Certification | UL Listed, DLC Listed (S-ZYK73Q), CEC Approved |
| DLC ID(s) | S-ZYK73Q |
| Warranty | 5 Years |
Data SheetDetails
Replace 150W to 200W HID Lamps to Cut Energy Use by 60% Per Lamp
- Five selectable power levels for flexible brightness and energy savings
- Color selectable: 3000K, 4000K, or 5000K to match your application
- EX39 mogul base for direct retrofit into existing HID sockets
- Bypass ballast design ensures reliable performance and efficiency
- Rated 50,000-hour life to reduce maintenance and relamping costs
- Universal 120-277V input for broad installation compatibility
A smart retrofit choice for wall packs, post tops, and area lighting, this lamp combines adjustable wattage and CCT with long-life LED efficiency for tailored performance and dependable savings.
