Retrofit T5 HO fixtures to LED without replacing a single tombstone — fits existing G5 sockets.
- 24W delivers 4,800 lumens at 186 lm/W — replaces 54W T5 HO and saves 30W per tube.
- T8 diameter with G5 bi-pin end caps — no new fixtures or tombstones, just swap the tube.
- ETL, ETL Sanitation, and DLC listed — 50,000-hour lifespan and 5-year warranty.
Retrofit T5 HO fixtures to LED without replacing a single tombstone — fits existing G5 sockets.
- 24W delivers 4,800 lumens at 186 lm/W — replaces 54W T5 HO and saves 30W per tube.
- T8 diameter with G5 bi-pin end caps — no new fixtures or tombstones, just swap the tube.
- ETL, ETL Sanitation, and DLC listed — 50,000-hour lifespan and 5-year warranty.
Choose options
Details
Cut Energy Costs by 55% — A Direct Retrofit for T5 HO Fluorescent Fixtures
- Saves 30 watts per tube versus 54W T5 HO fluorescent lamps — significant energy cost reductions at scale in warehouses, schools, and commercial facilities.
- T8 body with G5 miniature bi-pin endcaps fits directly into existing T5 fixture tombstones — no new fixture needed, just swap the tube.
- Delivers 4,800 lumens at 186 lm/W — matching or exceeding T5 HO light output while drawing a fraction of the power.
- Type B ballast bypass wiring eliminates the ballast from the circuit, removing a common failure point and reducing long-term maintenance costs.
- ETL, ETL Sanitation, and DLC listed — meets utility rebate requirements and is suitable for food service and sanitation-sensitive environments.
- Rated 50,000 hours (L70) with a 5-year warranty — long service life minimizes relamping labor in hard-to-reach or high-bay installations.
Ideal for retrofitting T5 HO fluorescent fixtures in warehouses, big-box retail, schools, gymnasiums, parking structures, and commercial kitchens.
Specs
| Wattage(s) | 24W |
| Replaces Wattage(s) | 54W (T5 HO) |
| Light Output | 4,800 lumens |
| Luminous Efficacy (lm/W) | 186 lm/W |
| Average Lamp Life | L70: 50,000 hours |
| Color Temperature(s) | 5000K |
| CRI (Color Accuracy) | >83 |
| Bulb Shape | T8 |
| Base Type | G5 (miniature bi-pin) |
| Lens Cover | Frosted |
| Ballast Compatibility | Type B |
| Installation | Bypass ballast and wire sockets directly to power |
| Input Voltage | 120-277VAC |
| Temperature Rating | -3°F to 113°F |
| Housing Material | Aluminum with polycarbonate lens |
| Certification | ETL, ETL Sanitation, DLC Standard |
| Warranty | 5 Years |
