45W Selectable RAB LED Post Top Retrofit Lamp - EX39
45W Selectable RAB LED Post Top Retrofit Lamp - EX39
45W Selectable RAB LED Post Top Retrofit Lamp - EX39
45W Selectable RAB LED Post Top Retrofit Lamp - EX39
Replace traditional metal halide or high pressure sodium HID lamps with significantly less energy usage and significantly more lamp life.
- Adjustable wattage and CCT allows for in-field customization
- Rated for use in enclosed fixtures in dry or damp locations
- Universal 100-277V voltage for flexible installation
Replace traditional metal halide or high pressure sodium HID lamps with significantly less energy usage and significantly more lamp life.
- Adjustable wattage and CCT allows for in-field customization
- Rated for use in enclosed fixtures in dry or damp locations
- Universal 100-277V voltage for flexible installation
Choose options
Specs
| Wattage(s) | 27W/36W/45W |
| Replaces Wattage(s) | 125W/150W/175W Metal Halide or High Pressure Sodium |
| Light Output | 4,185/5,580/6,970 |
| Luminous Efficacy (lm/W) | 155 lm/W |
| Average Lamp Life | 50,000 hours (L70) |
| Color Temperature(s) | 3000K/4000K/5000K (Field Adjustable via dip switch) |
| CRI (Color Accuracy) | 80 CRI |
| Dimming | Yes, by adjusting the wattage (light output) dipswitch located on the lamp. |
| Occupancy Sensor | Integrated AUX port for lamp-level sensor control |
| Bulb Shape | Post Top |
| Base Type | EX39 |
| Ballast Compatibility | UL Type B, Ballast Bypass |
| Installation | Universal mounting, horizontal or vertical, in open or enclosed fixtures in damp or dry locations |
| Enclosure Rating | IP64 |
| Input Voltage | 100-277V |
| Power Factor | ≥0.9 |
| THD (Total Harmonic Distortion) | ≤20% |
| Surge Protection | 4 kV |
| Operating Temperature | -22°F to 140°F (-30°C to 60°C) |
| Housing Material | Metal and polycarbonate |
| Housing Color | White + Gray |
| Certification | UL Listed, DLC Listed (S-497MXG) |
| DLC ID(s) | S-497MXG |
| Warranty | 5 Years |
Data SheetDetails
Replace up to 175W Metal Halide & High Pressure Sodium Lamps
- Cut energy consumption by up to 75%
- Selectable CCT: choose 3000K, 4000K, or 5000K for the perfect light quality
- Delivers 4,185–6,970 lumens of efficient, high-output lighting
- EX39 base installs directly into most existing HID sockets
- Rated for 50,000 hours to minimize maintenance and replacement costs
- Wide 120-277V input range for flexible installation
- 5 selectable power settings provide precise control of output and savings
Perfect for retrofitting wall packs, post tops, and area lights, this versatile LED lamp lets you fine-tune brightness and color temperature while delivering long-term energy and maintenance savings.
