Archipelago 1x4 LED Panel Light - Selectable Color & Wattage
Lumens:
Watts:
Color Temp:
5 Year Warranty
34 in stockConsistent lighting with superior visual comfort.
- Superior, non-stroboscopic lighting performance with backlit design and frosted PMMA lens
- Rely on consistent power output and color temperature thanks to the microchip programmed light engine and high density Samsung LED chips
- Tailored light solution that features field-selectable color temperatures of 3500K, 4000K, and 5000K, and selectable lumen outputs of 3,250, 3,900, and 4,500
- Easy installation—entire fixture weighs just 2.5 lbs
- Long operating life due to optimum heat dissipation and minimum light decay
- Includes short circuit overload protection, low-voltage prevention, and high efficiency electrical conversion (PF>0.9)
- Rated for use in indoor damp locations
- 5-year warranty
Saves $/year in energy costs*
Buying 12 or more?
Get a better price:
Consistent lighting with superior visual comfort.
- Superior, non-stroboscopic lighting performance with backlit design and frosted PMMA lens
- Rely on consistent power output and color temperature thanks to the microchip programmed light engine and high density Samsung LED chips
- Tailored light solution that features field-selectable color temperatures of 3500K, 4000K, and 5000K, and selectable lumen outputs of 3,250, 3,900, and 4,500
- Easy installation—entire fixture weighs just 2.5 lbs
- Long operating life due to optimum heat dissipation and minimum light decay
- Includes short circuit overload protection, low-voltage prevention, and high efficiency electrical conversion (PF>0.9)
- Rated for use in indoor damp locations
- 5-year warranty
Saves $/year in energy costs*
See how much you would save in energy
costs by allowing access to your location.
Choose options
Lumens:
Watts:
Color Temp:
5 Year Warranty
34 in stock
Buying 12 or more?
Get a better price:
Lumens:
Watts:
Color Temp:
5 Year Warranty
34 in stock
Buying 12 or more?
Get a better price:
SPECIFICATIONS
| Wattage(s) | 36W/30W/25W user selectable at install |
| Light Output | 4500/3900/3250 lumens dependent on selected wattage |
| Luminous Efficacy (lm/W) | Up to 130 lm/W |
| Average Lamp Life | 50,000 hours |
| Color Temperature(s) | 3500K, 4000K, 5000K user selectable at install |
| CRI (Color Accuracy) | >80 |
| Dimming | 0-10V |
| Lens Cover | Frosted PMMA lens |
| Working Environment | Indoors, Damp Location |
| Input Voltage | 120V-277V |
| Temperature Rating | -10°F to 125°F |
| Housing Material | 6063 aluminum frame |
| Housing Color | White |
| Dimensions | 12" x 48" x 1.2" |
| Weight | 2.5 lbs |
| Certification | DLC, UL Damp Location |
| Warranty | 5 Years |
FIXTURE CALCULATOR
Our easy tool tells you how many lights you need & how far apart they should be installed.
Click the cube icon
& enter the room's dimensions. "Workplane Height" is where the light levels will be measured from. For example, 2.5 ft is about desk height. "Suspension Length" is how far your fixture will hang below the ceiling. If the fixture will be flush with the ceiling or recessed, enter 0.
As you make changes, the layout updates instantly to show recommended fixture (luminaire) quantities and spacing. Click the printer icon
in the top bar to get a report you can print or share.
