A full-cutoff, field-tunable LED wall pack that provides zero-uplight illumination around factories, warehouses, walkways, and outdoor commercial areas.
- Selectable wattage (60W-120W) and CCT (3000K/4000K/5000K) to suit many sites
- Full-cutoff Type III optics eliminate upward light spill for dark-sky-friendly installation
- DLC Premium listing for top-tier rebate eligibility
Need More? Text/call (858) 650-9400
A full-cutoff, field-tunable LED wall pack that provides zero-uplight illumination around factories, warehouses, walkways, and outdoor commercial areas.
- Selectable wattage (60W-120W) and CCT (3000K/4000K/5000K) to suit many sites
- Full-cutoff Type III optics eliminate upward light spill for dark-sky-friendly installation
- DLC Premium listing for top-tier rebate eligibility
Choose options
Details
This field-selectable, full-cutoff LED wall pack excels as a budget-friendly option for lighting factories, warehouses, walkways, and commercial perimeters where precise light control and weatherproof performance are required.
- One Fixture, Broad Coverage: Wattage and CCT selectable at install — output up to 19,200 lumens at 3000K/4000K/5000K suits most project requirements, simplifying inventory.
- Eliminates Light Pollution & Spill: Type III full-cutoff optics deliver 160 lm/W efficiency with zero upward light — output goes exactly where it's needed, keeping neighbors and code enforcement happy.
- Automatic On/Off: Integrated photocell automates dusk-to-dawn operation to save energy and simplify operation.
- Rebate Eligible, Utility-Ready: DLC Premium listed and UL certified — qualifies for utility rebate programs and meets demanding commercial specifications.
- Built for the Elements: IP65-rated die-cast aluminum housing with polycarbonate lens and 6kV surge protection handles harsh outdoor conditions long-term.
- Flexible Control: 0–10V dimming compatible across 120–277VAC with a rated L70 lamp life of 50,000 hours.
Backed by ELEDLights' one-year direct warranty support — no chasing foreign manufacturers, no runaround, just fast resolution when you need it.
Specs
| Wattage(s) | 60W/90W/100W/120W Selectable |
| Replaces Wattage(s) | 400W |
| Light Output | 9,600/14,400/16,000/19,200 lumens |
| Luminous Efficacy (lm/W) | 160 lm/W |
| Average Lamp Life | L70: 50,000 hours |
| Color Temperature(s) | 3000K/4000K/5000K Selectable |
| CRI (Color Accuracy) | >80 |
| Dimming | 0-10V dimming |
| Light Distribution Pattern |
Type III
Learn More
×
Light Distribution OptionsType III Beam  Throws light forward and sideways. Suitable for either perimeter lighting, or, when fixtures are installed back-to-back, for interior poles. Type IV Beam  Provides forward directed light with minimal backlighting - great for perimeter installations. Type V Beam  Creates a square umbrella pattern of light ideal for interior (rather than perimeter) pole locations. |
| Lens Cover | Polycarbonate Lens |
| Installation | Wall Mount |
| Enclosure Rating | IP65 |
| Input Voltage | 120-277VAC, 50/60Hz |
| Surge Protection | 6kV |
| Temperature Rating | -40°F to +122°F (-40°C to +50°C) |
| Housing Material | Die-Cast Aluminum |
| Dimensions | 14.48" x 9.25" x 6.44" (367.8 mm x 235.0 mm x 163.7 mm) |
| Weight | 5.94 lbs (2.69k kg) |
| Certification | DLC Premium, UL |
| Warranty | 1 Year |
