63W Selectable Semi-Cutoff LED Wall Pack Light, DLC Premium
63W Selectable Semi-Cutoff LED Wall Pack Light, DLC Premium
63W Selectable Semi-Cutoff LED Wall Pack Light, DLC Premium
63W Selectable Semi-Cutoff LED Wall Pack Light, DLC Premium
One fixture, multiple configurations — this semi-cutoff wall pack lets you dial in the right wattage and color temperature on the job, no special orders needed.
- Selectable 33/53/63W and 3000K/4000K/5000K via DIP switch makes it versatile enough to cover nearly any exterior application.
- DLC Premium certified and 0-10V dimmable — qualifies for utility rebates and works with your existing control systems.
- IP65-rated, IK10-impact-resistant aluminum housing with a built-in dusk-to-dawn photocell means less hardware, less installation time, and long-term durability outdoors.
One fixture, multiple configurations — this semi-cutoff wall pack lets you dial in the right wattage and color temperature on the job, no special orders needed.
- Selectable 33/53/63W and 3000K/4000K/5000K via DIP switch makes it versatile enough to cover nearly any exterior application.
- DLC Premium certified and 0-10V dimmable — qualifies for utility rebates and works with your existing control systems.
- IP65-rated, IK10-impact-resistant aluminum housing with a built-in dusk-to-dawn photocell means less hardware, less installation time, and long-term durability outdoors.
Choose options
Specs
| Wattage(s) | 33W / 53W / 63W Selectable |
| Light Output | 4,290 to 8,850 lumens |
| Luminous Efficacy (lm/W) | 130 to 141 lm/W |
| Color Temperature(s) | 3000K / 4000K / 5000K Selectable |
| CRI (Color Accuracy) | 70 |
| Dimming | Yes |
| Dimming Range | 0-10V |
| Light Distribution Pattern |
Semi-Cutoff, 100° Beam Angle
Learn More
×
Light Distribution OptionsType III Beam  Throws light forward and sideways. Suitable for either perimeter lighting, or, when fixtures are installed back-to-back, for interior poles. Type IV Beam  Provides forward directed light with minimal backlighting - great for perimeter installations. Type V Beam  Creates a square umbrella pattern of light ideal for interior (rather than perimeter) pole locations. |
| Lens Cover | Tempered Glass Lens |
| Recommended Installation Height | 12 to 18 ft |
| Enclosure Rating | IP65, IK10 |
| Light Type | LED |
| Input Voltage | 120–277VAC, 50/60Hz |
| Driver Type | Constant Current (CC) |
| Operating Temperature | -40°C to +50°C (-40°F to +122°F) |
| Housing Material | Die Cast Aluminum Housing |
| Housing Color | Dark Bronze |
| Dimensions | 13.17" x 10.35" x 5.73" |
| Shipping Weight | 5 lb |
| Package Dimensions | 16.06" x 12.36" x 7.95" |
| Certification | DLC Premium, UL Listed |
| Warranty | 5 Years |
Data SheetDetails
This rugged, semi-cutoff LED wall pack is built for contractors and facility managers who need reliable exterior lighting with minimal fuss.
- Selectable wattage (33/53/63W) and CCT (3000K/4000K/5000K) via DIP switch — one fixture covers multiple job requirements.
- DLC Premium certified and 0-10V dimmable, making it rebate-eligible and compatible with most lighting control systems.
- IP65-rated die cast aluminum housing with IK10 impact resistance handles tough outdoor conditions without compromise.
- Integrated dusk-to-dawn photocell provides automatic on/off — no separate sensor required.
Backed by a 5-year warranty and in-stock for fast shipping — ELEDLights delivers the specs and support your project demands.
