RAB Lighting

9W LED Lamp Replaces 32W PLC CFL - Type A/B

RAB Lighting

0 Reviews

SKU: PLC-9-O-827-HYB

$17.00

Create warm, inviting light in 2-pin CFL fixtures — this 9W 2700K hybrid needs no ballast swap.

9W in warm 2700K replaces 26W and 32W CFLs — works in horizontal or vertical orientations.
Type A/B hybrid: plug-and-play on magnetic ballasts or bypasses them — handles mixed ballasts.
Mercury-free, UL listed for damp and enclosed fixtures, 50,000-hour lifespan.

Color Temperature

Variant

Need More? Text/call (858) 650-9400

Create warm, inviting light in 2-pin CFL fixtures — this 9W 2700K hybrid needs no ballast swap.

9W in warm 2700K replaces 26W and 32W CFLs — works in horizontal or vertical orientations.
Type A/B hybrid: plug-and-play on magnetic ballasts or bypasses them — handles mixed ballasts.
Mercury-free, UL listed for damp and enclosed fixtures, 50,000-hour lifespan.

Details

Install on magnetic CFL ballasts, or bypass the ballast on any CFL light for additional energy savings
Omnidirectional light pattern fills spaces evenly with comfortable illumination
50,000-hour service life reduces maintenance cost by providing dependable lighting with fewer replacements
Mercury-free and safe — eco-friendly choice compared to older CFLs
UL Listed for use in a wide range of fixtures, including open & enclosed and damp locations

Ideal for commercial and residential PLC light fixtures where installation flexibility, energy efficiency, and unifrorm lighting are needed.

Wattage(s)	9W
Replaces Wattage(s)	26W or 32W CFL with G24d, GX24d, G24q, or GX24q base
Light Output	1,150 lumens (2700K), 1,000 lumens (3000K), 1050 lumens (3500K), 1,100 lumens (4000K)
Luminous Efficacy (lm/W)	128 lm/W (2700K), 111 lm/W (3000K), 117 lm/W (3500K), 122 lm/W (4000K)
Average Lamp Life	L70: 50,000 Hours
Color Temperature(s)	2700K, 3000K, 3500K or 4000K
CRI (Color Accuracy)	80 CRI
Bulb Shape	PLC
Bulb Orientation	Omnidirectional
Base Type	2-Pin G24d
Lens Cover	Frosted
Ballast Compatibility	Hybrid Type A/B install
Working Environment	Indoor
Enclosure Rating	Damp & dry locations Enclosed or open fixtures
Input Voltage	120-277V, 50/60Hz
Power Factor	>0.9
THD (Total Harmonic Distortion)	20%
Temperature Rating	-4°F to 113°F (-20°C to 45°C)
Housing Material	Polycarbonate
Certification	UL Listed
Warranty	5 years

Data Sheet

Install Guide

	9W LED Lamp Replaces 32W PLC CFL - Type A/B	8.5W Horizontal LED Lamp Replaces 32W PLC CFL - Type A/B	8.5W Vertical LED Lamp Replaces 32W PLC CFL - Type A/B
Color Temperature (CCT)	2700K, 3000K, 3500K or 4000K	3000/3500/4000K	3000/3500/4000K
Base Type	2-Pin G24d	2-Pin G24d	2-Pin G24d
Ballast Compatibility	Hybrid Type A/B install	Hybrid Type A/B install	Hybrid Type A/B install
Enclosure Rating	Damp & dry locations Enclosed or open fixtures	Damp & dry locations Enclosed or open fixtures	Damp & dry locations Enclosed or open fixtures
Certification	UL Listed	UL Listed	UL Listed
	$17.00	$18.00 View Details	$18.00 View Details
