8.5W RAB Vertical LED Lamp Replaces 32W PLC CFL - Type A/B
8.5W RAB Vertical LED Lamp Replaces 32W PLC CFL - Type A/B
8.5W RAB Vertical LED Lamp Replaces 32W PLC CFL - Type A/B
RAB Lighting
0 Reviews
8.5W RAB Vertical LED Lamp Replaces 32W PLC CFL - Type A/B
Regular price
One vertical PLC lamp replaces 18W, 26W, or 32W CFL — with field-selectable color temperature.
- 8.5W delivers 960–1,050 lumens in 3 selectable CCTs (3000K/3500K/4000K) — G24d and G24q.
- Type A/B hybrid works on magnetic ballasts or wires direct — handles any fixture without sorting.
- 50,000-hour life, DLC listed for rebates, saves nearly 75% vs. the CFL it replaces.
Color Temperature
One vertical PLC lamp replaces 18W, 26W, or 32W CFL — with field-selectable color temperature.
- 8.5W delivers 960–1,050 lumens in 3 selectable CCTs (3000K/3500K/4000K) — G24d and G24q.
- Type A/B hybrid works on magnetic ballasts or wires direct — handles any fixture without sorting.
- 50,000-hour life, DLC listed for rebates, saves nearly 75% vs. the CFL it replaces.
Choose options
Regular price
Color Temperature
Regular price
Color Temperature
Specs
| Wattage(s) | 8.5W |
| Replaces Wattage(s) | 26W or 32W CFL with G24d, GX24d, G24q, or GX24q base |
| Light Output | 1100/1120/1150 lumens |
| Luminous Efficacy (lm/W) | 129/132/135 lm/W |
| Average Lamp Life | L70: 50,000 Hours |
| Color Temperature(s) | 3000/3500/4000K |
| CRI (Color Accuracy) | 80 CRI |
| Bulb Shape | PLC |
| Bulb Orientation | Vertical |
| Base Type | 2-Pin G24d |
| Lens Cover | Frosted |
| Ballast Compatibility | Hybrid Type A/B install |
| Working Environment | Indoor |
| Enclosure Rating |
Damp & dry locations Enclosed or open fixtures |
| Input Voltage | 120-277V AC, 50/60Hz |
| Power Factor | >0.9 |
| THD (Total Harmonic Distortion) | 20% |
| Temperature Rating | -4°F to 113°F (-20°C to 45°C) |
| Housing Material | Polycarbonate |
| Certification | UL Listed |
| Warranty | 5 years |
Install GuideDetails
Vertical Mount LED CFL Replacement Reduces Operating Costs by 50%-75%
- Selectable color temperature at install to match site needs
- Plug and play with magnetic ballast, or bypass either ballast type for direct-wire savings
- Replaces 18W, 26W, and 32W CFL lamps, providing the same light with far less energy use
- 50,000-hour rated life for years of reliable performance and reduced maintenance costs
- UL Listed for use in damp and enclosed fixtures
Ideal for vertical PLC fixtures in offices, retail, and multifamily applications where versatility and efficiency are key.
