RAB Lighting

7W LED Lamp Replaces 13W/18W PLC CFL - Type A/B

RAB Lighting

0 Reviews

SKU: PLC-7-O-835-HYB

$15.00

Replace 18W CFL lamps in 2-pin G24d fixtures — hybrid LED works on ballasts or wires direct.

7W replaces 18W CFL at half the energy cost — omnidirectional output in horizontal or vertical.
Type A/B hybrid installs plug-and-play on magnetic ballasts or bypasses — handles mixed ballasts.
Mercury-free, UL listed for damp and enclosed fixtures, 50,000-hour lifespan, 5-year warranty.

Color Temperature

Variant

Need More? Text/call (858) 650-9400

Replace 18W CFL lamps in 2-pin G24d fixtures — hybrid LED works on ballasts or wires direct.

7W replaces 18W CFL at half the energy cost — omnidirectional output in horizontal or vertical.
Type A/B hybrid installs plug-and-play on magnetic ballasts or bypasses — handles mixed ballasts.
Mercury-free, UL listed for damp and enclosed fixtures, 50,000-hour lifespan, 5-year warranty.

Details

Flexible installation — works with magnetic CFL ballasts, or direct-wire for any PLC fixture & can be used with both G24d and G24q sockets
Omnidirectional output — provides uniform illumination in all directions
Replaces up to 13W & 18W CFL lamps, delivering savings without sacrificing light quality
50,000-hour rated life reduces relamping and service costs
Mercury-free for an environmentally safe upgrade from CFL
UL Listed — trusted for commercial applications in both open and enclosed fixtures
Rated for use in damp locations

Ideal for ceiling fixtures, sconces, and wall packs where even light distribution and installation flexibility are important.

Wattage(s)	7W
Replaces Wattage(s)	13W or 18W CFL with G24d, GX24d, G24q, or GX24q base
Light Output	880 lumens (3500K), 900 lumens (4000K)
Luminous Efficacy (lm/W)	126 lm/W (3500K), 129 lm/W (4000K)
Average Lamp Life	L70: 50,000 Hours
Color Temperature(s)	3500K or 4000K
CRI (Color Accuracy)	80 CRI
Dimming	Type A install: 0-10V dimming with compatible ballast Type B install: Not suggested
Bulb Shape	PLC
Bulb Orientation	Omnidirectional
Base Type	2-Pin G24d
Lens Cover	Frosted
Ballast Compatibility	Hybrid Type A/B install
Enclosure Rating	Damp & dry locations Enclosed fixtures
Input Voltage	120-277V, 50/60Hz
Power Factor	>0.9
THD (Total Harmonic Distortion)	20%
Temperature Rating	-4°F to 113°F (-20°C to 45°C)
Housing Material	Polycarbonate
Certification	UL Listed
Warranty	5 years

Install Guide

Data Sheet

	7W LED Lamp Replaces 13W/18W PLC CFL - Type A/B	9W LED Lamp Replaces 32W PLC CFL - Type A/B	8.5W Vertical LED Lamp Replaces 32W PLC CFL - Type A/B
Color Temperature (CCT)	3500K or 4000K	2700K, 3000K, 3500K or 4000K	3000/3500/4000K
Base Type	2-Pin G24d	2-Pin G24d	2-Pin G24d
Ballast Compatibility	Hybrid Type A/B install	Hybrid Type A/B install	Hybrid Type A/B install
Enclosure Rating	Damp & dry locations Enclosed fixtures	Damp & dry locations Enclosed or open fixtures	Damp & dry locations Enclosed or open fixtures
Certification	UL Listed	UL Listed	UL Listed
	$15.00	$17.00 View Details	$18.00 View Details
